1.Configure device through wired/wireless network.
2.Support horizontal and vertical PTZ; control viewing angle freely.
3.Support soundwave and wire configuration.
4.Built-in MIC and speaker,support two-way talk.
5.Support multiple RS433 alarming methods,magnetic door,bracelet etc.
6.Support High/Standard/Flow definition switch.
7.Support 64G local storage.
8.Record file format:MP4.
9.Support Android/IOS/Windows PC client remote view.
10.Capable of seeing face clearly within 8m in daytime; 10m IR distance at night.

Model/Specification		JVS-H411
Camera	Image Sensor	1/4″CMOS
	Resolution	1280×720
	Pixel	1.0MP
	Compression	H.264/JPEG
	Frame Rate	25fps
	Bit Rate	64Kbps～8Mbps
	Min.Illumination	0Lux(IR ON)
Lens	Lens Mount	M12
	Lens	3.6mm
	View Angle	71°
	Focus	Fixed
Function	Privacy Mask	4 Rectangle areas
	Exposure Control	Auto
	Gain Control	Auto
	White Balance	Auto
	Day & Night	IR cut filter with auto switch，  Support Color to Black
	Video Adjust	Supports contrast, brightness,  saturation, sharpness adjustment
	Remote Operation	System、Stream、User、Network Management
	Motion Detection	Support
	Alarm	E-mail、Client
	Voice Intercom	Support
	Local Storage	64G
PTZ Control	Rotation Angel	Horizon:355°  Vertical:120°
	Preset	127
	Automatic Cruise	1 line
	Horizontal Scan	1 Line
Interface	Audio Input	1个 Built-in MIC
	Audio Output	1 Built-in Speaker
	Net	1 RJ45 10M/100M adaptive interface
	Alarm In	1 CH
	Alarm Output	1 CH
	TF slot	1 standard TF card slot
	Reset	Restore to the factory settings
Network	Ethernet	10/100M Ethernet
	Wireless	WIFI
	Dual Stream	Support
	Protocol	HTTP,TCP/IP,ICMP,UDP,SMTP,FTP,DHCP,DNS,PPPOE
	Transmission	Internal Cloudsee Protocol
	Browser	IE8+,Chrome18+,Firefox5.0+,Safari5.02+
	Connection	6 CH
	User Permission	Up to 13 users，Three level authority：  Administrator、User、Visitor
General	Infrared Lamp	10 LED Lamps
	IR distance（m）	10m
	Best distance（m）	8m
	Temperature	-20℃～55℃
	Humidity	10%～90%
	Power Supply	DC 5V/1A
	Power	≦3.2W
	Material	White ABS+PC
	Size(W×H×D)(mm)	95×123×122
	Weight(g)	300
	Installation	Wall/Ceil/Desk Mounting
